All-in-one design saves on-site installation and commissioning costs;
Full inverter design, high efficiency, and energy saving
Wide voltage adaptability, allowing voltage ±20% fluctuation
RS485 communication interface is standard, CAN communication is optional
Incoming call self-start function, and provide a variety of alarms and protection functions
Small size, compact construction, protection class IPX5
PTC heating to meet the heating needs of equipment in low-temperature scenarios
Can be operated 24 hours a day, designed for a service life of more than 10 years
Operating temperature range: 30-55
Technical Parameter
Model
CTS0080N
Cooling Capacity
kW
8
Power Consumption (35°C)
kW
3.08
EER (35°C)
/
2.6
Power Consumption (45°C)
kW
3.64
EER (45°C)
/
2.2
Rated Outlet Temperature
ºC
18
Electric Heating
kW
2
Pipe Diameter
/
NW26
Flow Rate
L/min
50
Head (Lift)
kPa
80
Refrigerant
/
R410A
Dimensions
Width
mm
275
Depth
mm
1100
Height
mm
800
Unit Weight
kg
95
Power Supply
V/Hz
220V/50Hz
Operating Temperature Range
ºC
-30~55
External Circulation Airflow Method
Advance or retreat
Installation Method
Embedded
