All-in-one design saves on-site installation and commissioning costs;
Full inverter design, high efficiency, and energy saving
Wide voltage adaptability, allowing voltage ±20% fluctuation
RS485 communication interface is standard, CAN communication is optional
Incoming call self-start function, and provide a variety of alarms and protection functions
Small size, compact construction, protection class IPX5
PTC heating to meet the heating needs of equipment in low-temperature scenarios
Can be operated 24 hours a day, designed for a service life of more than 10 years
Operating temperature range: 30-55
Technical Parameter
Model
CTS0100W
Cooling Capacity
kW
10
Power Consumption (35°C)
kW
4.16
EER (35°C)
/
2.4
Power Consumption (45°C)
kW
5.26
EER (45°C)
/
1.9
Rated Outlet Temperature
ºC
18
Electric Heating
kW
2
Pipe Diameter
/
NW26
Flow Rate
L/min
90
Head (Lift)
kPa
90
Refrigerant
/
R410A
Dimensions
Width
mm
820
Depth
mm
1100
Height
mm
450
Unit Weight
kg
130
Power Supply
V/Hz
220V/50Hz
Operating Temperature Range
ºC
-30~55
External Circulation Airflow Method
Advance or retreat
Installation Method
Embedded Horizontal
Company Profile
Cooltec Cooling Technology (Qingdao) Co., Ltd. is a high-tech enterprise integrating R&D, manufacturing, sales, and service. At present, the company's main products are industrial air conditioners and water chillers. The core R&D team of Coltec comes from a famous industrial refrigeration enterprise in the US and has world-leading industrial refrigeration technology.
* Excellent team to serve overseas customers. We try to understand customer and their need. The company offers excellent pre, during, and after sales service. Consultative sales model is our aim in expansion of overseas market
* Excellent design capability, originated from excellent engineers, with first-class enterprise working experience.
* Short lead time, quick response * Inexpensive sample/demo product price & quickest delivery in industry. * Convenient geographical location, to better serve international markets. All three factories are export friendly located with good traffic.
ONE-STOP COOLING SOLUTION
* Headquartered in Qingdao, China * Suzhou factory was established in 2009, strong at manufacturing cabinets, heat exchanger & economy cabinet air conditioners. * Shenzhen factory was established in 2015 focusing on, precision air conditioner, UPS, data center, IT & energy storage cooling solution * Qingdao factory was founded in 2020, focusing on telecom cabinet air conditioner, industrial indoor cabinet air conditioner, outdoor electric cabinet air conditioner & cabinet air conditioner R&D. * The Qingdao headquarters has a professional team of overseas sales representatives and managers.
