All-in-one design saves on-site installation and commissioning costs;
Full inverter design, high efficiency, and energy saving
Wide voltage adaptability, allowing voltage ±20% fluctuation
RS485 communication interface is standard, CAN communication is optional
Incoming call self-start function, and provide a variety of alarms and protection functions
Small size, compact construction, protection class IPX5
PTC heating to meet the heating needs of equipment in low-temperature scenarios
Can be operated 24 hours a day, designed for a service life of more than 10 years
Operating temperature range: 30-55
Technical Parameter
Model
CTS0200L
Cooling Capacity
kW
20
Power Consumption (35°C)
kW
7.69
EER (35°C)
/
2.6
Power Consumption (45°C)
kW
9.09
EER (45°C)
/
2.2
Rated Outlet Temperature
ºC
18
Electric Heating
kW
12
Tube Diameter
/
DN50
Flow Rate
L/min
200
Head (Lift)
kPa
150
Refrigerant
/
R410A
Dimensions
Width
mm
980
Depth
mm
630
Height
mm
2400
Unit Weight
kg
275
Power Supply
V/Hz
380V/50Hz
Operating Temperature Range
ºC
-30~55
External Circulation Airflow Method
Forward and backward
Installation Method
Standing cabinet
